Z.P.H. JAN - Wire products; fencing systems

Wire mesh for forestry

These wire mesh models are used in forestry, highway/motorway fencing and farming.

Technical parameters

  • horizontal wire diameter 1,6 or 2 mm:
    tensile strength:
    1100 N/mm²
  • vertical wire diameter 1,6 or 2 mm:
    tensile strength:
    500 N/mm²
  • horizontal wire diameter 2,5 mm:
    tensile strength:
    1200 N/mm²

See the forest wire mesh fencing projects  here

Wire mesh types:

Forestry wire mesh type L (Light)
guide wire thickness: ø2,0 ±0,09 mm
middle wire thickness: ø1,6 ±0,09 mm
zinc coating: 80 g/m²
Forestry wire mesh L 100/10/15 Forestry wire mesh L 100/10/30 Forestry wire mesh L 100/13/15 Forestry wire mesh L 100/13/30 Forestry wire mesh L 120/9/15
Wire mesh type 100/10/15 100/10/30 100/13/15 100/13/30 120/9/15
Metres in reel [mb] 50 50 50 50 30
Reel weight [kg] 15,60 12,00 18,00 15,00 10,00
Forestry wire mesh L 125/13/15 Forestry wire mesh L 125/13/30 Forestry wire mesh L 125/13/30z Forestry wire mesh L 125/14/15 Forestry wire mesh L 125/15/30
Wire mesh type 125/13/15 125/13/30 125/13/30z 125/15/15 125/15/30
Metres in reel [mb] 50 50 50 50 50
Reel weight [kg] 19,10 15,25 14,75 22,00 17,00
Forestry wire mesh L 150/13/15 Forestry wire mesh L 150/13/30 Forestry wire mesh L 150/13/30 Forestry wire mesh L 150/15/15 Forestry wire mesh L 150/15/30
Wire mesh type 150/13/15 150/13/30 150/13/30 150/15/15 150/15/30
Metres in reel [mb] 50 50 30 50 50
Reel weight [kg] 20,45 16,00 9,60 22,50 16,50
Forestry wire mesh L 150/17/15 Forestry wire mesh L 150/17/30 Forestry wire mesh L 160/15/15 Forestry wire mesh L 160/15/30 Forestry wire mesh L 160/20/15
Wire mesh type 150/17/15 150/17/30 160/15/15 160/15/30 160/20/15
Metres in reel [mb] 50 50 50 50 50
Reel weight [kg] 25,00 19,50 24,00 18,00 30,00
Forestry wire mesh L 160/20/30 Forestry wire mesh L 160/23/15 Forestry wire mesh L 160/23/30 Forestry wire mesh L 180/24/15 Forestry wire mesh L 200/17/15
Wire mesh type 160/20/30 160/23/15 160/23/30 180/24/15 200/17/15
Metres in reel [mb] 50 50 30 50 50
Reel weight [kg] 23,00 30,40 24,10 35,00 27,50
Forestry wire mesh L 200/17/30 Forestry wire mesh L 200/22/15 Forestry wire mesh L 200/22/30 Forestry wire mesh L 200/25/15 Forestry wire mesh L 200/25/30
Wire mesh type 200/17/30 200/22/15 200/22/30 200/25/15 200/15/30
Metres in reel [mb] 50 50 50 50 50
Reel weight [kg] 21,00 33,00 26,00 34,20 26,80
Forestry wire mesh type M (Medium)
guide wire thickness: ø2,5 ±0,09 mm
middle wire thickness: ø2,0 ±0,09 mm
zinc coating: 80 g/m²
Forestry wire mesh M 125/13/15 Forestry wire mesh M 125/13/30 Forestry wire mesh M 160/15/15 Forestry wire mesh M 160/15/30 Forestry wire mesh M 160/20/15
Wire mesh type 125/13/15 125/13/30 160/15/15 160/15/30 160/20/15
Metres in reel [mb] 50 50 50 50 30
Reel weight [kg] 29,00 23,30 34,88 27,62 41,64
Forestry wire mesh M 160/20/30 Forestry wire mesh M 160/23/15 Forestry wire mesh M 200/17/15 Forestry wire mesh M 200/17/30 Forestry wire mesh M 200/22/15
Wire mesh type 160/20/30 160/23/15 200/17/15 200/17/30 200/22/15
Metres in reel [mb] 50 50 50 50 50
Reel weight [kg] 34,39 49,35 41,20 32,18 47,98
Forestry wire mesh M 200/22/30 Forestry wire mesh M 200/25/15
Wire mesh type 200/22/30 200/25/15
Metres in reel [mb] 50 50
Reel weight [kg] 38,92 52,07
Forestry wire mesh type M-AS (Medium)
guide wire thickness: ø2,5 ±0,09 mm
middle wire thickness: ø2,0 ±0,09 mm
zinc coating: 215 g/m²
Forestry wire mesh M-AS 125/13/15 Forestry wire mesh M-AS 160/15/15 Forestry wire mesh M-AS 160/15/30 Forestry wire mesh M-AS 160/20/15 Forestry wire mesh M-AS 160/23/15
Wire mesh type 125/13/15 160/15/15 160/15/30 160/20/15 160/23/15
Metres in reel [mb] 50 50 50 50 50
Reel weight [kg] 29,00 34,88 27,62 41.64 49,35
Forestry wire mesh M-AS 200/17/15 Forestry wire mesh M-AS 200/17/30 Forestry wire mesh M-AS 200/22/15 Forestry wire mesh M-AS 200/22/30 Forestry wire mesh M-AS 200/25/15
Wire mesh type 200/17/15 200/17/30 200/22/15 200/22/30 200/25/15
Metres in reel [mb] 50 50 50 50 50
Reel weight [kg] 41,20 32,18 47,98 38.92 52,07

Manufacturing and packing

Fill out and submit the contact form for more information.
